Fire Alarm Linkage for Emergency Passage
The AT104 tripod turnstile gate can be connected to a fire alarm system. When a fire signal is received, the arm automatically drops down and the passage opens for emergency evacuation. This helps ensure that people can leave quickly and safely during emergencies.

Anti-Impact and Illegal Intrusion Alarm
The AT104 supports anti-impact and illegal intrusion alarm functions. If someone attempts to force the arm, climb over the gate, enter without authorization, or pass in the reverse direction, the system can trigger sound and light alarms. Alarm records can also be uploaded to the management platform for security monitoring.

Adjustable Auto-Reset Delay
After authorization by card, QR code, fingerprint, face recognition, or other access methods, the gate waits for the user to pass. If no one passes within the preset time, the system automatically cancels the permission and locks again. The reset delay time can be adjusted according to the actual site requirements.

Independent Entry and Exit Control
The AT104 turnstile tripod supports independent control for both entry and exit directions. Each direction can be set as controlled passage, free passage, or no passage. For example, the entrance can require card verification while the exit can be set as free passage. This makes the product suitable for many different management modes.

Pedestrian Counting and Attendance Statistics
The AT104 can be connected to a backend system to record entry and exit data. It can help count the number of people entering, leaving, and staying inside the area in real time. This function is useful for construction sites, factories, gyms, schools, exhibitions, scenic spots, and other places that need attendance or traffic reports.

Anti-Pinch and Anti-Collision Protection
The product is designed with mechanical limit protection and buffering protection. These features help prevent hand pinching, reduce hard impact, protect the internal mechanism, and improve user safety during passage. The smooth movement also helps extend the service life of the turnstile.

Remote Backend Management
After networking, the AT104 can support remote opening, remote closing, permission setting, access record checking, alarm record viewing, and device status monitoring. This helps security managers control multiple turnstile gates from one management platform.

Compatible with Multiple Identification Devices
The AT104 ticket checking tripod turnstile can be integrated with many types of access control devices, including RFID card readers, IC/ID card readers, QR code scanners, barcode ticket scanners, face recognition terminals, fingerprint scanners, ID card readers, visitor systems, and existing third-party access control controllers.

If customers already have their own identification devices, the turnstile can be customized according to the device size and installation requirements.

Power Failure Auto-Drop and Manual Unlock
When power is disconnected, the turnstile arm can automatically drop down to allow free passage. The device can also support mechanical manual unlocking, ensuring that pedestrian movement is not blocked during power failure.

LED Passage Status Indicator
The AT104 is equipped with clear LED indicators. Red and green arrow lights show whether passage is allowed or forbidden. This helps guide pedestrians clearly and improves passage efficiency at busy entrances.

Water-Resistant, Dust-Resistant and Impact-Resistant Body
The AT104 adopts a durable stainless steel body and sealed structure. It can resist dust, rain, and daily impact under suitable installation conditions. It is suitable for indoor, semi-outdoor, and some outdoor environments. For long-term outdoor use, a canopy or additional protection is recommended.

Quiet and Smooth Operation
The AT104 can provide smooth and quiet operation through stable mechanical design and optional hydraulic damping or fully automatic movement. It is suitable for locations where low noise and stable operation are important, such as schools, hospitals, office buildings, and gyms.

Temporary Visitor Authorization
The turnstile supports temporary visitor access. Visitors can pass by temporary QR code, temporary card, or backend authorization. The permission can be limited by time or usage count and can automatically expire after the valid period.

Blacklist Interception
When connected with an access control platform, the AT104 can identify blacklisted users. If a restricted person attempts to pass through card, QR code, fingerprint, or face recognition, the system can refuse access and trigger an alarm.
