Brushless motor Swing Turnstile AT202

Traffic Direction LED Indication：This brushless motor swing turnstile adopts high-visibility red and green LED warning lights to display real-time traffic directions. The forward green LED indicates an available passage, while the top indicator lights dynamically switch status according to the gate’s working condition, enabling intuitive pedestrian traffic judgment for the intelligent swing turnstile.

Multi-Color Lane Status LED Prompt：Equipped with clear LED status prompts for different lane states: green for permitted passage, blue for standby mode, and flashing red to restrict unauthorized access, providing straightforward traffic status reminders for various commercial scenarios.

Infrared Anti-Intrusion Alarm Function：Built-in infrared sensor module supports intelligent alarm triggering. It activates an alarm promptly once unauthorized intrusion or reverse passage behavior is detected, effectively preventing illegal entry and improving site security.

Emergency Release & Power-Off Reset：In case of sudden power outages or emergency situations, the turnstile automatically unlocks to allow free pedestrian passage and ensure personnel safety. The swing turnstile will reset to normal working status automatically after power restoration.

Automatic Access Reset Function：After successful card swiping or access verification, if pedestrians fail to pass within the valid time window, the system will automatically cancel the access permission to avoid invalid passage authorization and improve access management accuracy.

Anti-Collision Protection Design：The swing gate arm features intelligent collision protection. When subjected to external impact beyond the safe range, the mechanical arm rebounds and resets automatically without structural damage, extending the service life of the dual-lane swing turnstile.

Reverse Entry Locking Prevention：The system supports reverse passage interlock protection. It keeps the gate locked to block reverse entry attempts, effectively regulating one-way or two-way pedestrian traffic order for office and commercial building entrances.

Level 2 Anti-Tailgating Security：With Level 2 anti-tailgating security performance, the brushless motor swing turnstile triggers an alarm when unauthorized tailgating behavior occurs, preventing multiple people from passing with a single valid access credential and greatly improving the security of the swing turnstile.

Fast Anti-Intrusion Unlocking Control：The gate maintains a locked state by default without valid opening signals. It supports fast unlocking within 0.2 seconds (adjustable speed) after receiving legal verification signals, balancing security and passage efficiency.

Diversified Custom Working Modes：This dual-lane swing turnstile supports multiple adjustable operating modes via the mainboard menu, including one-way passage, two-way passage, infrared induction opening, and signal-triggered opening, adapting to diverse site management needs.

Independent Traffic Direction Settings：Both entry and exit lanes can be independently configured to three traffic states: Controlled Traffic, Free Traffic, and No Traffic, realizing flexible and personalized pedestrian access control for different scenarios.

Passage Request Memory Function：The system can record multiple simultaneous valid passage signals from the same or opposite directions and execute access actions sequentially. The memory quantity and function switch are fully customizable to meet customized management demands.

Professional Safety Protection：Built with complete safety configurations including lightning protection and leakage protection functions, ensuring stable and safe long-term operation of the swing turnstile in outdoor and indoor commercial environments.

Customizable Voice Prompt System：Supports intelligent voice prompts for entry and exit actions. Multiple voice content options and language packages are available for customization, improving human-machine interaction experience.

Open Expansion Interface Protocol：Comes with a free open development kit and standard interface protocol, convenient for secondary development, equipment debugging, and system docking, providing strong scalability for this intelligent swing turnstile access control system.
