Access Indicator: LED warning lights indicate traffic direction using highly visible green and red lights. The LED is green when passage is permitted; blue in standby mode; and flashing red when passage is denied.

Alarm Function: Infrared sensor alarm function for unauthorized and reverse intrusion.

Emergency Exit Function: Allows free passage in emergencies or power outages, automatically resetting upon power restoration.

Automatic Reset: After a valid card is swiped, the system automatically cancels the user’s passage permission if passage is not permitted within the designated time.

Anti-Collision: When the door experiences an impact exceeding safe limits, the mechanical arm automatically resets to its original position. The mechanism remains undamaged.

Reverse Entry: If someone attempts to enter from the opposite direction, the door will remain locked.

Anti-Pinch Function: Dual mechanical and infrared anti-pinch function. If the arm encounters obstruction during reset, it automatically stops or rebounds, simultaneously emitting an alarm signal.

Anti-Tailgating: If multiple people attempt to pass without permission, the door will alarm. Security Level 2.

Intrusion Prevention Function: The door automatically locks before receiving a valid opening signal. When a valid signal is received, the gate will unlock within 0.2 seconds (adjustable).

Multiple operating modes are available: one-way passage, two-way passage, infrared gate opening, or passage controlled by a gate opening signal sent to the main board, all configurable via the main board menu.

Logic Judgment: Multiple infrared sensors monitor the channel status in real time, accurately determining and authorizing passage without obstruction.

Passage Modes: Entry and exit directions can be independently set to 【Controlled Passage】/【Free Passage】/【No Passage】.

Passage Request Memory Function: When two or more valid passage signals are given simultaneously (including same-direction and opposite-direction), the system will remember all passage requests and complete each passage action sequentially (the number of requests to remember and whether to select the memory function can be customized according to customer requirements).

Safety Features: Equipped with lightning and leakage protection.

Multi-level Anti-collision Buffer Function: In case of unauthorized passage or gate breaching, the gate arm buffers at the corresponding angle and activates immediate counter-thrust and clutch locking, while simultaneously triggering an alarm. This provides humane protection against injury while significantly reducing mechanical damage caused by frequent or continuous collisions. Multiple alarm modes: alarms for unauthorized entry, anti-intrusion, tailgating, and timeout.

Voice prompts: prompts for entry and exit; multiple voice prompts can be set (customizable).

Integration protocol: Free development kit protocol provided for easy control and debugging; highly scalable.
